Mini Pc Models
M-216
M-225
M-325
M-545
M-745
MINI Delivers GIANT Value
- Zero Noise & Extra Slim
- Vastly Energy Efficient
- Highly Cost Effective
- Green Technology
Technical Specifications
| Processor | Intel® Celeron™ J1800 (2.41 GHz, Max upto 2.58GHz) Dual-Core processor |
| Memory | 1GB DDR3 RAM (Upto 8 GB) |
| Internal Storage | 16 GB SATA FLASH (Expandable upto 32 GB Flash or 1TB HDD) |
| LED Monitor (Optional) | 15.6" / 18.5" / 19.5" / 21.5" |
| Key Board & Mouse | Wire/Wireless |
| VGA on Die | Intel® HD Graphics, support VGA,HDMI display interface |
| Memory | 2x dual-channel 1333MHz DDR3 Slots, upto 8 GB |
| Expansion Slots | 1x mini PCle (half size) |
| LAN | Realtek Gigalan |
| Power Supply | 120W DC-DC Power Supply and 12V/5A Adapter |
| Audio | 5.1 channel HD Audio |
| Back Panel I/O Ports | 1xPS2 keyboard/mouse common port 1xVGA port 1xCOM port 4xUSB2.0 ports 1USB 3.0 port 1xRJ45 port 10M/100Mbps 1x 3 ports audio jacks. |
| Side Panel I/O | 2x USB 2.0 ports audio port jacks |
| Dimension | 60*190*250mm (W*H*D) |
| Weight | N.W 2.0KG G.W2.3KG |
| Colour | Black |
| Processor | Intel Dual Core 3.00GHz(3MB L2 Cache) |
| Memory | 2 GB DDR3 RAM |
| Internal Storage | "2.5" SATA HDD Support 500GB ( Expandable upto 2TB) |
| LED Monitor (Optional) | 15.6" / 18.5" / 19.5" / 21.5" |
| Key Board & Mouse (Optional) | Wire/Wireless |
| VGA on Die | Intel® HD Graphics, support VGA,HDMI display interface |
| Memory | 2x dual-channel 1600 MHz DDR3 slots,upto 16GB |
| Expansion Slots | 1x mini PCle (half size) |
| LAN | Realtek Gigalan |
| Power Supply | 120W DC-DC Power Supply and 12V/5A Adapter |
| Audio | 5.1 channel HD Audio |
| Back Panel I/O-Ports | 1x PS2 keyboard/mouse common port 1x HDMI port 1x VGA port 1x COM port 4x USB 2.0 ports 2x USB 3.0 ports 1x RJ45 port 10M/100Mbps1x 1x 3-port audio jacks |
| Side Panel I/O | 2x USB 2.0 ports audio port jacks |
| 60*190*250mm (W*H*D) | |
| Weight | N.W 2.0KG G.W2.3KG |
| Colour | Black |
| Processor | Intel Core i3 4th Gen 3.40 GHz, 3 MB L3-Cache Memory |
| Memory | 2 GB DDR3 RAM |
| Internal Storage | "2.5” SATA HDD Support 500 GB (Expandable upto 1 TB)" |
| LED Monitor (Optional) | 15.6” / 18.5” / 19.5” / 21.5” |
| Key Board & Mouse (Optional) | Wire/Wireless |
| VGA on Die | Intel® HD Graphics, support VGA,HDMI display interface |
| Memory | 2x dual-channel 1600MHz DDRIII slots, up to 16GB |
| Expansion Slots | 1x mini PCIe (half size) |
| LAN | Realtek GigaLan |
| Power Supply | 120W DC-DC Power Supply and 12V/5A Adapter |
| Audio | 5.1channel HD Audio |
| Back Panel I/O Ports | 1x PS2 keyboard/mouse common port 1x HDMI port 1x VGA port 1x COM port 4x USB 2.0 ports 2x USB 3.0 ports 1x RJ45 port 1x 3-port audio jacks |
| Side Panel I/O | 2x USB 2.0 ports audio port jacks |
| Dimension | 60*190*250mm（W*H*D） |
| Weight | N.W 2.0KG G.W2.3KG |
| Colour | Sliver/Black |
| Processor | Intel Core i5 4th Gen 3.20 GHz ( Upto 3.40GHz) 6 MB L3-Cache Memory |
| Memory | 4 GB DDR3 RAM |
| Internal Storage | "2.5” SATA HDD Support 500 GB (Expandable upto 1 TB)" |
| LED Monitor (Optional) | 15.6” / 18.5” / 19.5” / 21.5” |
| Key Board & Mouse (Optional) | Wire/Wireless |
| VGA on Die | Intel® HD Graphics, support VGA,HDMI display interface |
| Memory | 2x dual-channel 1600MHz DDRIII slots, up to 16GB |
| Expansion Slots | 1x mini PCIe (half size) |
| LAN | Realtek GigaLan |
| Power Supply | 120W DC-DC Power Supply and 12V/5A Adapter |
| Audio | 5.1channel HD Audio |
| Back Panel I/O Ports | 1x PS2 keyboard/mouse common port 1x HDMI port 1x VGA port 1x COM port 4x USB 2.0 ports 2x USB 3.0 ports 1x RJ45 port 1x 3-port audio jacks |
| Side Panel I/O | 2x USB 2.0 ports audio port jacks |
| Dimension | 60*190*250mm（W*H*D） |
| Weight | N.W 2.0KG G.W2.3KG |
| Colour | Sliver/Black |
| Processor | Intel Core i7 4th Gen 3.50 GHz, 8 MB L3-Cache Memory |
| Memory | 4 GB DDR3 RAM |
| Internal Storage | "2.5” SATA HDD Support 500 GB (Expandable upto 1 TB)" |
| LED Monitor (Optional) | 15.6” / 18.5” / 19.5” / 21.5” |
| Key Board & Mouse (Optional) | Wire/Wireless |
| VGA on Die | Intel® HD Graphics, support VGA,HDMI display interface |
| Memory | 2x dual-channel 1600MHz DDRIII slots, up to 16GB |
| Expansion Slots | 1x mini PCIe (half size) |
| LAN | Realtek GigaLan |
| Power Supply | 120W DC-DC Power Supply and 12V/5A Adapter |
| Audio | 5.1channel HD Audio |
| Back Panel I/O Ports | 1x PS2 keyboard/mouse common port 1x HDMI port 1x VGA port 1x COM port 4x USB 2.0 ports 2x USB 3.0 ports 1x RJ45 port 1x 3-port audio jacks |
| Side Panel I/O | 2x USB 2.0 ports audio port jacks |
| Dimension | 60*190*250mm（W*H*D） |
| Weight | N.W 2.0KG G.W2.3KG |
| Colour | Sliver/Black |
...
